Model NO.:

Image Sensor

SONY IMX415 (1/2.8” )

Max. Resolution

3840(H) *2160 (V)

Pixel Size

1.45µmx1.45µm

Compression format

MJPEG  / YUY2（YUYV）

Resolution & frame

3840x2160@ 30fps MJPEG / 2592x1944@ 30fps MJPEG

2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG

1920x1080@ 30fps MJPEG/ 1280x960@30fps MJPE

1280x720@ 30fps MJPEG / 800 x 600@ 30fps MJPEG

640x480@ 30fps MJPEG /  320x240@ 30fps MJPEG

3840x2160@ 1fps YUY2 / 2592x1944@ 1fps YUY2

2048x1536@ 3fps YUY2 /1600x1200@ 5fps YUY2

1920x1080@ 5fps YUY2/1280x960@5fps YUY2

1280x720@ 5fps YUY2 / 800 x 600@ 20fps YUY2

640x480@ 30fps YUY2 /  320x240@ 30fps YUY2

Center definition

1000LW/PH (Center)

S/N Ratio

30dB

Sensitivity

0.65V/lux-sec@550nm

Minimum illumination

0.2lux

Shutter Type

Electronic rolling shutter / Frame exposure

Connecting Port type

USB2.0 High Speed

AEC

Support

AEB

Support

AGC

Support

Auto Focus

Support

Adjustable parameters

Brightness, Contrast, Hue, Saturation, Sharpness, Gamma, White

Balance, Exposure

Lens Parameter

110 degree wide angle low distortion M12 lens (HFOV111 degree, VFOV 74 degree)

IR filter: 650±10nm

Power supply& connector

USB BUS POWER  4P-2.0mm socket

Power Voltage

DC5V

Power Current

200mA

Board Size

38*38/ 32*32MM

Storage Temperature

-20°C to 70°C

Work Temperature

0°C to 60°C

USB Cable

1M(2M/3M/5M optional)

Operating System support

Win XP/Vista/Win7/Win8 / Linux with UVC（above linux-2.6.26）

MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC
